TA10 (Gr12) Titanium Tube - High Corrosion Resistance

Origin: Baoji, Shaanxi, China
Brand: FRL metal
Density: 4.51 g/cm³
Grade: TA10 Gr12
Standard: ASTM B337, ASTM B338, ASTM B861
Size: Customizable
Surface: polished/pickling
Certification: ISO9001
Delivery time: 7-15 days Packaging Details: Plywood case
Product Description

Introduction to TA10(Gr12)Titanium Tube

TA10 titanium tube (equivalent to Grade 12 per ASTM B337/B338) is a commercial pure titanium tube with corrosion resistance, particularly in oxidizing media such as chlorine-containing solutions and seawater. It offers good formability, weldability, and biocompatibility, making it one of the most widely used titanium grades for chemical processing, marine engineering, and medical applications.

Our TA10 titanium tubes are manufactured per strict quality standards. Each batch comes with Mill Test Certificate (MTC) to ensure full traceability. Available in various sizes and specifications to meet your requirements. Custom dimensions and drawings are accepted.



TA10(Gr12) titanium tube is mainly used in the following fields:

1. Aerospace: Hydraulic system, fuel system and exhaust system of aircraft.
2. Chemical industry: Pipes and equipment for various corrosive media.
3. Medical: Human implants and medical devices.
4. Marine engineering: Desalination equipment, offshore oil platforms and submarines.
5. Sports equipment: High-end bicycle racks, golf clubs and tennis rackets.



TA10(Gr12) Titanium Tube Picture display

TA10 Gr12 Titanium Tube ASTM B337 FRL Metal TA1(Gr12)titanium tube close-up smooth surface finish T10(Gr12) titanium tube end view polished surface



Chemical composition of titanium materials

Grade Main Chemical Constituent %
Ti Al V Mo Ni Pd Fe C N H O
Gr1 Remainder — — — — — 0.2 0.08 0.03 0.01 0.18
Gr2 Remainder — — — — — 0.3 0.08 0.03 0.01 0.25
Gr3 Remainder — — — — — 0.3 0.08 0.05 0.01 0.35
Gr4 Remainder — — — — — 0.5 0.08 0.05 0.01 0.4
Gr5 Remainder 5.5~6.75 3.5~4.5 — — — 0.4 0.08 0.05 0.01 0.2
Gr7 Remainder — — — — 0.12~0.25 0.3 0.08 0.03 0.01 0.25
Gr9 Remainder 2.5~3.5 2.0~3.0 — — — 0.25 0.08 0.03 0.01 0.15
Gr12(TA10) Remainder — — 0.2~0.4 0.6~0.9 — 0.3 0.08 0.03 0.01 0.25


TA10 titanium tube advantages

1. High strength: TA10 titanium tube has a high specific strength (ratio of strength to density) and can withstand greater stress at the same weight.
2. Corrosion resistance: It exhibits excellent corrosion resistance in a variety of corrosive media, including seawater, acidic and alkaline solutions.
3. Good thermal stability: It can still maintain its mechanical properties in high temperature environment and is not prone to thermal deformation.
4. Biocompatibility: For the medical field, TA10 titanium tube is non-toxic and harmless to the human body and will not cause rejection.
5. Low density: The density is only 4.51 g/cm³, which is lighter than traditional steel, so it has significant weight advantages in the fields of aerospace and sports equipment.



Our Packaging

Package
Package
Package
Package
Package
Package
Package
Package
Package
Package
Package
Package
Package
Package
Package
Package
Package
Package
Package
Package

About FRL Metal

Baoji Freelong New Material Technology Development Co., Ltd is headquartered in Baoji City — known as "China's Titanium Valley." As a professional manufacturer and exporter, we specialize in the production, OEM processing, and global sales of zirconium, titanium, nickel, niobium, tantalum and their alloys.

With years of industry experience, we have earned the trust of numerous clients and strategic partners worldwide. Our products have been authorized by leading enterprises across Australia, Korea, Germany, the United States, the United Kingdom, Malaysia, Central Asia, the Middle East, Taiwan and other regions.

At FRL Metal, quality and service are not just commitments — they are our core values. We strictly adhere to international standards (ASTM, AMS, etc.) and maintain ISO 9001 certification throughout our production process. Every batch undergoes rigorous testing to ensure it meets or exceeds customer specifications.

Whether you need standard products or custom solutions, our experienced team is ready to provide professional support from inquiry to delivery. We look forward to building a successful partnership with you.

product-7019-1526

Frequently Asked Questions (FAQ)

Q1: What is TA10 titanium tube?
A: TA10 titanium tube is equivalent to Grade 12 titanium per ASTM B337/B338 standards. It is a commercial pure titanium tube with corrosion resistance, particularly in oxidizing media such as chlorine-containing solutions and seawater.

Q2: What standards do your TA10 titanium tubes comply with?
A: Our TA10 titanium tubes are manufactured per ASTM B337 (standard specification for titanium and titanium alloy pipes) and ASTM B338 (specification for seamless and welded titanium and titanium alloy tubes). We can also meet AMS and other international standards upon request.

Q3: What sizes are available for TA10 titanium tubes?
A: We offer TA10 titanium tubes in various outer diameters, wall thicknesses, and lengths. Standard sizes are available in stock, and custom dimensions can be manufactured per your requirements. Please contact us for specific size availability.

Q4: What are the main applications of TA10 titanium tubes?
A: TA10 titanium tubes are widely used in chemical processing equipment, marine engineering (desalination plants, offshore platforms), medical devices and implants, aerospace hydraulic systems, and high-performance sports equipment due to their 内部技能lent corrosion resistance and biocompatibility.

Q5: Can you provide Mill Test Certificates?
A: Yes, every batch comes with a Mill Test Certificate (MTC) detailing chemical composition and mechanical properties to ensure compliance with ASTM standards.

Q6: What surface finishes are available?
A: We offer polished and pickled surface finishes for our TA10 titanium tubes, depending on the application requirements. Custom surface treatments are also available upon request.
