Zirconium-4 sheet is a high-performance zirconium alloy material, composed of zirconium (Zr) and a small amount of tin (Sn), iron (Fe), chromium (Cr) and other elements. Compared with pure zirconium, zirconium-4 has better corrosion resistance, mechanical properties and thermal stability, and is especially suitable for high temperature, high pressure and highly corrosive environments. It is widely used in nuclear energy, chemical, electronics, aerospace and other industries, and is an important engineering material in key areas.
| Name | Zircaloy-4 plate |
| Material | Zirconium alloy |
| Grade | UNS R60804 |
| Purity | >99.5% |
| Density | 6.51g/cm3 |
| Standard | ASTM B352 |
| Size | 0.3-50mm*1000*6000mm |
| Shape | Plate/sheet |
| Surface | Polished |
| MOQ | 1kg |
| Custom | Yes, we can OEM,ODM |
| Package | Plywood case |
![]() |
![]() |
![]() |
1. Nuclear energy industry: manufacturing nuclear fuel cladding, pressure tubes, reactor support structures, steam generators, etc., because of its low thermal neutron absorption cross-section, it can improve the utilization rate of nuclear fuel.
2. Chemical industry: used for heat exchangers, storage tanks, pipelines, pumps and valves in strong acid and alkali environments, especially for corrosive media such as hydrochloric acid, sulfuric acid, and hydrofluoric acid.
3. Aerospace: used to manufacture structural components, jet engine parts, high temperature resistant protective layers, etc. in high temperature environments.
4. Electronic industry: used as high-purity semiconductor equipment parts, sputtering targets, electron tube components, etc. to meet the precision requirements of electronic components.
5. Medical industry: Due to its good biocompatibility, it can be used to manufacture orthopedic implants, medical devices, etc.
| / | Zr704 (UNS R60704) | Zircaloy-4 (UNS R60804) |
|---|---|---|
| Alloy type | Zirconium-tin (Zr-Sn) alloy, industrial grade | Zirconium-tin-iron-chromium (Zr-Sn-Fe-Cr) alloy, nuclear grade |
| Standard | ASTM B551 | ASTM B352 |
| Main ingredients | Zr + 1.0–2.0% Sn + 0.20–0.40% Fe+Cr | Zr + 1.20–1.70% Sn + 0.18–0.24% Fe + 0.07–0.13% Cr (Ni ≤0.007%) |
| Characteristics | Higher strength and creep resistance than commercially pure zirconium; good corrosion resistance | Nuclear grade; low neutron absorption; good corrosion and radiation resistance in high-temperature water and steam |
| Application areas | Chemical processing equipment, heat exchangers, corrosion-resistant structural components | Nuclear fuel rod cladding tubes and reactor structural materials |
Industrial grades — ASTM B551/B551M (GB/T 26314)
| Grade (UNS) | Standard | Zr+Hf, min % | Hf, max % | Sn, % | Fe+Cr, % | Nb, % | C, max % | O, max % | H, max % | N, max % | Notes |
|---|---|---|---|---|---|---|---|---|---|---|---|
| Zr702 (R60702) | ASTM B551 / GB/T 26314 (Zr-3) | ≥99.2 | ≤4.5 | — | ≤0.20 | — | ≤0.05 | ≤0.16 | ≤0.005 | ≤0.025 | Commercially pure (unalloyed) zirconium; excellent corrosion resistance; widely used in chemical and marine engineering. |
| Zr704 (R60704) | ASTM B551 | ≥97.5 | ≤4.5 | 1.0–2.0 | 0.20–0.40 | — | ≤0.05 | ≤0.18 | ≤0.005 | ≤0.025 | Zirconium-tin (Zr-Sn) alloy; higher strength and creep resistance than R60702. |
| Zr705 (R60705) | ASTM B551 / GB/T 26314 (Zr-5) | ≥95.5 | ≤4.5 | — | ≤0.20 | 2.0–3.0 | ≤0.05 | ≤0.18 | ≤0.005 | ≤0.025 | Zirconium-niobium (Zr-Nb) alloy; high strength and good toughness with good corrosion resistance. |
Nuclear-grade grade — ASTM B352/B352M (GB/T 26314, Zr-4)
| Grade (UNS) | Standard | Zr+Hf | Hf, max % | Sn, % | Fe, % | Cr, % | Fe+Cr, % | Ni, max % | C, max % | O, % | H, max % | N, max % | Notes |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Zircaloy-4 (R60804) | ASTM B352 / GB/T 26314 (Zr-4) | Bal. | ≤0.010 | 1.20–1.70 | 0.18–0.24 | 0.07–0.13 | 0.28–0.37 | ≤0.0070 | ≤0.027 | 0.09–0.16 | ≤0.0025 | ≤0.0080 | Nuclear-grade Zr-Sn-Fe-Cr alloy; used for fuel rod cladding tubes and reactor structural materials. |
Notes: All values are weight percent (wt%). "—" means the element is not specified or not an alloying element. R60703/Zr703 is not an ASTM B551 or GB/T 26314 grade; if supplied, report actual MTC values. Oxygen for R60804 may be specified by agreement between purchaser and manufacturer per ASTM B352.
1. Equipment Advantages
There are planing machine, milling machine, annealing furnace, laser cutting machine, bending machine, leveling machine, punching machine and forging hammer, etc.
2. The Product Advantages
Large quantity of spot stock, can provide samples, can be processed and customized according to the drawings.
3. Price Advantages
Source factory production, no middlemen, factory price delivery.
4. Quality Advantages
Provide material report, if customer needs, can provide third party test report.
5.And Service Advantages
Professional customer service throughout the service for you, if you encounter product quality problems can be returned free of charge.










Baoji Freelong New Material Technology Development Co., Ltd is headquartered in Baoji City — known as "China's Titanium Valley." As a professional manufacturer and exporter, we specialize in the production, OEM processing, and global sales of zirconium, titanium, nickel, niobium, tantalum and their alloys.
With years of industry experience, we have earned the trust of numerous clients and strategic partners worldwide. Our products have been authorized by leading enterprises across Australia, Korea, Germany, the United States, the United Kingdom, Malaysia, Central Asia, the Middle East, Taiwan and other regions.
At FRL Metal, quality and service are not just commitments — they are our core values. We strictly adhere to international standards (ASTM, AMS, etc.) and maintain ISO 9001 certification throughout our production process. Every batch undergoes rigorous testing to ensure it meets or exceeds customer specifications.
Whether you need standard products or custom solutions, our experienced team is ready to provide professional support from inquiry to delivery. We look forward to building a successful partnership with you.

![]() |
![]() |
![]() |
![]() |
![]() |
